MRCOOL Universal Series 2 or 3 Ton DC Inverter Initary Cooling Only Condenser, MDUCO18024036

by MRCOOL
SKU MDUCO18024036
In stock | ETA: to
Save $465.00
Original Price $2,429.00
Current Price $1,964.00

Notify me when back in stock

FREE EXPRESS SHIPPING

Process orders in 1 business day

Stress Free Returns

2 Year Returns

Primum Quality

Top Tier Products, Even Better Customer Care

5 Year Warranty

We Believe In Our Products & Our Team

MRCOOL Universal Series 2 or 3 Ton DC Inverter Initary Cooling Only Condenser


The Universal Cooling-Only Condenser has been designed with versatility and efficiency in mind. With its compact side-discharge design, this Universal condenser ideal for places where limited space is a factor. It also offers different options when it comes to installing and connecting the refrigerant piping. These include soldering, flared-screw connections, or the MRCOOL signature No-Vac, Quick-Connect Line Set, for DIY installers or those who want to simplify and shorten the installation process. The Universal Cooling-Only Condenser comes complete with multiple safeguards that protect and monitor the unit to help ensure safe and smooth operation over the life of the system. All of this in a unit that is capable of a 20 SEER rating.

Key Features

  • Up to 20 SEER in 2 Ton Mode, Up to 18 SEER in 3 Ton Mode
  • Compatible with any third party air handler and thermostat including the MRCOOL® Universal WiFi Thermostat or WiFi/Nest
  • Low Ambient Cooling Down to 39.2 Degrees F
  • Condensers Can Be Field Converted to smaller size using Dip Switch Setting
  • AHRI Certified & ETL listed
  • Slim Design
  • Quiet 55-58dB(a) Operation
  • Gold Fin® condenser: corrosion resistant - live on the coast? Don't worry, our condenser is built to resist long term corrosion
  • Multiple Connection Types: Pre-Charged No-Vac® Quick Connect® Line Set, Sweat Braze Connection, or Flare Connection
  • 10 Year Registered Limited Warranty

PRODUCT SPECIFICATIONS:

Product Dimensions 37"W x 18-1/8"D x 32-1/4"H
Product Weight 185.2 lbs
SEER 20 in 2 Ton Mode
18 in 3 Ton Mode
EER 12.5 in 2 Ton Mode
12.2 in 3 Ton mode
CFM 3,000 in 3 Ton Mode
34,70 in 4 Ton Mode
Tonnage 2-3 Ton
Cooling Capacity 24,000, 36,000 BTU
Electrical Requirements Requires a minimum of 208V-230V/60HZ/24A-35A (please check your home meets this electrical requirement prior to purchase)
Phase 1
Cycle 60 Hz
Max Fuse Breaker 35 A
Min Circuit Ampacity 24 A
Color Gray
Refrigerant Type R-410A
Refrigerant Volume 118.24 oz
Decibel Rating 55-57 dBA
Liquid Line Size 3/8 in
Suction Line Size 3/4in
Certifications ETL
AHRI
Warranty 10 Year Limited Warranty
