MRCOOL Advantage 4th Gen 36K BTU Ductless Single Zone Mini Split (HVAC Technician Required), A-36-HP-230C
OFFERS
John D. "Great service! Highly recommend."
Jane S. "Saved $50 on my order."
Mike T. "Fast and reliable support."
Transform your indoor climate with the MRCOOL Advantage 4th Gen 36K BTU Ductless Single Zone Mini Split (HVAC Technician Required), A-36-HP-230C. This powerful mini-split system is designed to deliver efficient heating and cooling for larger spaces, ensuring you stay comfortable year-round. With a robust 36,000 BTU capacity, it quickly adjusts to your desired temperature, providing optimal comfort no matter the weather outside.
The MRCOOL Advantage stands out with its innovative features, including the SmartHVAC WiFi Control Module, allowing you to effortlessly control your system from anywhere via Apple and Android smart devices. Compatible with Amazon Alexa and Google Assistant, this system offers modern convenience at your fingertips. Additionally, its corrosion-resistant Gold Fin® condenser ensures durability, making it ideal for coastal living where harsh conditions are a concern.
Installation by a licensed professional is required, ensuring you benefit from a hassle-free setup. With a compact outdoor unit designed for easy maintenance and a comprehensive warranty that covers the compressor and parts, you can trust the MRCOOL Advantage to provide reliable performance for years to come. Elevate your home's comfort and efficiency with this state-of-the-art ductless mini-split system.
Specifications of MRCOOL Advantage 4th Gen 36K BTU Ductless Single Zone Mini Split (HVAC Technician Required), A-36-HP-230C:
Condenser Dimensions | 37.24"W x 16.14"D x 31.89"H |
Condenser Weight | 150.13 lbs |
Air Handler Dimensions | 49.57"W x 11.10"D x 14.25"H |
Air Handler Weight | 40.34 lbs |
SEER | 17.5 |
SEER2 | 17.5 |
EER2 |
8.5 |
COP 47 |
2.81 |
HSPF |
hspf4/hspf5 : 12/8 |
HSPF2 | hspf4-2/hspf5-2: 8.7/6.8 |
Tonnage | 3 |
Cooling Capacity |
36,000 BTU |
Heating Capacity | 36,000 BTU |
Voltage |
Requires a minimum of 208-230V/60HZ/28-35A (please check your home meets this electrical requirement prior to purchase) |
Phase | 1 |
Cycle |
60 Hz |
Max Fuse Breaker |
35 A |
Min Circuit Ampacity | 28 A |
Color | White |
Max Coverage Area | 1,500 sqft |
Zone Capacity | 1 |
Refrigerant Type | R-410A |
Refrigerant Volume | 119.9 oz |
Decibel Rating | 40 to 54.5 dBA |
Decibel Rating Low | 40 dBA |
Decibel Rating High | 54.5 dBA |
Inverter | Yes |
Min Ambient Cool |
5F - 122F |
Min Ambient Heat |
5F - 75F |
Line Set Length | 25ft |
Max Lineset Length | 98.42 ft |
Liquid Line Size |
3/8 in |
Suction Line Size |
5/8 in |
Compressor Motor Type |
Rotary |
Condenser Fan Motor RPM |
950/250 |
Blower Motor RPM |
1200/950/750 |
Auxiliary Heater Available | No |
Modes | Fan Only Quiet Mode Auto Cool |
Wifi Compatibility | Yes |
App Compatibility | Yes |
Compatible with | IOS Android |
Includes | Remote Batteries |
Certifications | UL Listed CSA LIsted ETL Listed |
Registered Warranty |
1-Year Compressor, 2-Year Parts and 1-Year remote |
Restricted States | GU;PR;VI |
Designed to be installed by an HVAC technician, this 4th-generation MRCOOL Advantage 4th Gen 36K BTU Ductless Single Zone Mini Split (HVAC Technician Required), A-36-HP-230C Advantage Series is now efficiently rated at 17.5 SEER. Immediately upon installation, this MRCOOL Advantage 4th Gen 36K BTU Ductless Single Zone Mini Split (HVAC Technician Required), A-36-HP-230C quality mini-split system provides high-quality comfort with a price point that’s hard to beat. This MRCOOL Advantage 4th Gen 36K BTU Ductless Single Zone Mini Split (HVAC Technician Required), A-36-HP-230C combination of air handler and condenser is great for those looking for quality, efficiency, quiet operation, and affordability. The high-performance compressor features the eco-friendly refrigerant R-410A which is chlorine-free.
This MRCOOL Advantage 4th Gen 36K BTU Ductless Single Zone Mini Split (HVAC Technician Required), A-36-HP-230C Advantage system incorporates both quality and superior technological control with its WiFi control module. MRCOOL Advantage 4th Gen 36K BTU Ductless Single Zone Mini Split (HVAC Technician Required), A-36-HP-230C aids in easier setup and you’re able to control it with the SmartHVAC app, or your Amazon Alexa or Google Assistant
