MRCOOL 4.1 Ton R410A Upflow Cased Evaporator Coil, MCVP49CNPA

Introducing the MRCOOL 4.1 Ton R410A Upflow Cased Evaporator Coil (MCVP49CNPA), a premium solution designed to enhance the efficiency of your HVAC system.

This high-performance evaporator coil is built for flexibility and durability, making it an ideal choice for both heat pumps and air conditioners. Its innovative design allows for quick and straightforward installation, ensuring you can achieve optimal cooling and heating performance without unnecessary delays.

This evaporator coil is part of the Signature Series and is engineered to work seamlessly with other MRCOOL components, such as the Signature Series condenser and gas furnace or modular blower. When properly paired, this coil can achieve impressive efficiency ratings of up to 16 SEER, ensuring that you enjoy a comfortable indoor environment while minimizing energy costs. With its robust construction, this coil promises long-lasting performance, making it a reliable addition to your HVAC system.

Upgrade your home's heating and cooling capabilities with the MRCOOL 4.1 Ton R410A Upflow Cased Evaporator Coil. Experience the perfect balance of efficiency and performance, ensuring your space remains comfortable throughout the year.

MCVP49CNPA Key Features

Interlocking door assemblies and snug line seal grommets to minimize air leakage

All units UL Listed and AHRI Certified

One of the lowest water retentions drains pans in the industry to minimize mold and mildew growth

External cabinet mounted distributor body designed for easy changing of orifice sizes and fast TXV connections

Foil-face insulation for easy cleaning

All drain pans are compatible with UV lights

Two dual drains on front of coil for installation flexibility of drain lines around a furnace vent and utility connections.

Superior service access to components, with tubing located at door split and foil-face insulation

Aluminum tubing, hairpins, distributors, and header tubes. Copper refrigerant connections for easy brazing to both liquid and suction lines.

Tubing located at door split for easy coil service or cleaning

Tightly sealed, painted steel cabinet with wall to wall insulation to ensure <2% air leakage

MCVP49CNPA PRODUCT SPECIFICATIONS:

Product Dimensions

21"W x 21"D x 29 1/2"H

Product Weight

70 lbs

Tonnage

4.1

Cooling Capacity

49,000

Color

Gray

Refrigerant Type

R-410A

Drain Connection Size

3/4

Lineset Included

Line Set Length

15ft, 25ft, 35ft, 50ft

Max Lineset Length

50 ft

Lineset Fitting Type

Sweat

Liquid Line Size

3/8

Suction Line Size

7/8

Certifications

UL
AHRI

Warranty

Registered 10 Year Parts Warranty

MCVP49CNPA Manual
