  Pioneer® Diamante Pro Series 36,000
    BTU 19 SEER2 Ductless Mini-Split Air
    Conditioner Inverter+ Heat Pump Full
     Set 230V with 16 Ft. Kit

Pioneer® Diamante Series 9,000 BTU 20 SEER Ductless Mini-Split Air Conditioner Inverter+ Heat Pump Full Set 115V with 16 Ft. Kit COMPLETE SET

Upgrade your home’s climate control with the Pioneer® Diamante Pro Series 36,000 BTU 19 SEER2 Ductless Mini-Split Air Conditioner Inverter+ Heat Pump System. This high-efficiency system provides powerful cooling and heating capabilities, with a 19 SEER2 rating that ensures energy savings without sacrificing comfort. Featuring advanced inverter+ technology, it delivers consistent and quiet temperature regulation year-round.

The system comes with a full set of components and a 16 ft. installation kit, making setup quick and easy. Operating on 230V, this Pioneer® Diamante Pro Series unit is designed to provide reliable, long-lasting performance for your home’s heating and cooling needs.

Enjoy effortless climate control and lasting comfort with this top-of-the-line mini-split air conditioner heat pump system.



Features of Pioneer® Diamante Pro Series 36,000 BTU 19 SEER2 Ductless Mini-Split Air Conditioner Inverter+ Heat Pump Full Set 230V with 16 Ft. Kit:

Technical Information

Performance Data

  • Power Supply: 208~230V, 60Hz, 1Ph
  • Cooling Rated Capacity: 36,000 BTU/h
  • Cooling Capacity Range: 10,800~39,600 BTU/h
  • Cooling SEER2: 19 BTU/W.h
  • Cooling EER2: 9 BTU/W.h
  • Heating Rated Capacity: 36,000 BTU/h
  • Heating Capacity Range: 10,800~39,600 BTU/h
  • Heating HSPF2 (Region IV/V): 8.5 / 7.0 BTU/W.h
  • Heating C.O.P.2 (47°F/5°F): 3.01 / 1.75 W/W
  • Refrigerant Type: R410A
  • Suitable Area: 900~1,250 Sq.F

Indoor Unit DataPioneer® Diamante Pro Series 36,000 BTU 19 SEER2 Ductless Mini-Split Air Conditioner Inverter+ Heat Pump Full Set 230V with 16 Ft. Kit SAMPLE PHOTO

  • Part Number: WS036GLFI19HLE
  • Air Flow (Hi/Med/Lo): 847 / 700 / 641 CFM
  • Sound Level (Hi/Med/Lo): 48 / 43 / 38 dB(A)
  • Net Dimensions (WDH): 47  x 10-1/4 x 14-1/4 Inches
  • Carton Dimensions (WDH): 49-3/4 x 13-1/4 x 17-1/4 Inches
  • Net / Gross Weight: 39.7 / 48.5 lbs

Outdoor Unit Data

  • Part Number: YN036GLFI19RPE
  • Breaker Needed: 25A (double-pole)
  • Sound Level: 63 dB(A)
  • Net Dimensions (WDH): 35-3/4 x 14-1/8 x 31-1/2 Inches
  • Carton Dimensions (WDH): 40-1/2 x 18-3/4 x 34 Inches
  • Net / Gross Weight: 114.6 / 126.8 lbs

Manuals & Documents


    Pioneer® Diamante Pro Series 36,000
    BTU 19 SEER2 Ductless Mini-Split Air
    Conditioner Inverter+ Heat Pump Full
                 Set 230V with 16 Ft. Kit

Summary

  • High Efficiency Diamante Pro Ductless Mini Split Heat Pump System
  • Cooling capacity: 36,000 BTU/H with 19 SEER2 / 9 EER2 efficiency
  • Heating capacity: 36,000 BTU/H with 8.5 HSPF2 / 3.01 COP2 efficiency
  • Voltage: 208~230V, 60Hz, 1Ph
  • High Wall Mounted Air Conditioning & Heating System
  • Variable Speed DC Inverter Operation Mode
  • Low Ambient Unit (-13°F)
  • AHRI Estimated Annual Operating Costs:
    • Cooling: $280.00
    • Heating: $895.00



Pioneer® Diamante Series 9,000 BTU 20 SEER Ductless Mini-Split Air Conditioner Inverter+ Heat Pump Full Set 115V with 16 Ft. Kit SAMPLE PHOTO

What's Included

  • Indoor Unit
  • Outdoor Unit
  • Wireless Remote Control (with wall holder and batteries)
  • 16 Ft. Copper Lines
  • 16 Ft. Electrical Wire
  • 10 Ft. Drain for indoor/outdoor
  • Wall Passage Sleeve
  • Putty for Wall Hole
  • Leak Guard Sealer
  • Wrapping Tape
  • Installation Manual
  • User’s Manual

Our Guarantee

  • 5 years warranty for Parts
  • 5 years warranty for Compressor

Free Express Shipping on All orders within the USA

Read Our Shipping Policy Here

30 Day Free Returns on all orders

Read about our Returns Policy Here
